Presenting the ZCX DJ 531, a state-of-the-art glue dispensing robot that applies adhesive precisely out of 300ml bottles. This cutting-edge device has many characteristics that are designed to satisfy the various requirements of contemporary industry.
With its many route possibilities (point, line, arc, circle, and irregular curve), the DJ 531 allows for extremely accurate 3D glue potting. A brushless DC motor enables its fast potting speed and low operating noise, ensuring effective operations and excellent results. The integrated electrostatic eliminator guarantees excellent performance even in delicate situations by maintaining a static level below ±100V, hence ensuring static-free dispensing. The self-compensation feature improves user experience and productivity by streamlining operations.
This robot provides unmatched adaptability to multiple applications with its X and Y working area arrays, translational rotation capabilities, and support for 3-axis interpolation. It also incorporates picture importation capabilities with ease, supporting file formats such as PLT, TCF, and G code for increased flexibility. With the DJ 531 by ZCX, experience the glue pouring of the future.
1. The path can be point, line, arc, circle, irregular curve and so on 3D glue potting. |
2. High potting speed, low working noise and brushless DC motor, better potting effects. |
3. Electrostatic eliminator to make sure the static under ±100V |
4. Self compensation function, make operation more easier. |
5. X, Y working area array, translational rotation operation function, reverse material plate, adapt to different application. |
6. Support 3-axis straight line, arc, ellipse interpolation |
7. Support image importing function, the file format can be PLT, TCF and G code. |
Working Distance | X-axis: 500 mm Y-axis: 300 mm Z-axis: 100mm |
Repeating Precise | ±0.02mm-0.05MM (≦±0.02mm can be customized) |
Control System | Teaching hand-held control panel |
Drive Method | Stepping Motor+synchronous belt+Straight line sliding trial |
File Saving Space | For 3Mbps file, can save 999 working paths |
Supported File Format | CAD, CoreldRAW |
Unload moving speed | 300mm/s(Max 800mm/s can be customized) |
Maximum Load | Y-axis/ Z-axis: 5KG/2KG |
Power supply | AC220V 50 – 60HZ 350W |
Machine Dimension | L: 580mm*W: 620mm*H:590mm |
